The IXW-MA-SOFT is a multi-purpose adaptor with licenses for 1, 5, or 10 IX-SOFT installations.
The IXW-MA-SOFT comes with 4 contact inputs and 10 relay outputs. The inputs on the adaptor can be used to send a command to a specific station to perform a task. The relays on the adaptor can be associated to a specific station and programmed to change state when relay output 1 or 2 on the associated station changes state. This is beneficial when door release contacts need to be located inside the facility at a secure location, instead of at the door station.
The IXW-MA-SOFT is surface mounted to a 3 or 4-gang box or ring. Wire terminations are made via option connectors supplied with the unit. Each connecting wire will need to be secured with a wire nut or crimp connector.
The IXW-MA-SOFT is a PoE device, and can be programmed via IX Support Tool 5.0 or later.
IXW-MA-SOFT includes 1 IX-SOFT license.
IXW-MA-SOFT-5 includes 5 IX-SOFT licenses.
IXW-MA-SOFT-10 includes 10 IX-SOFT licenses.
FEATURES
- Supports 1, 5 or 10 IX-SOFT licenses
- PoE powered (802.3af)
- 4 contact inputs
- 10 relay outputs
- Outputs 1-4 are Form C
- Outputs 5-10 are Form A
- 24V AC/DC 500mA relay contact rating
- Programmed via IX Support Tool
SPECS
Power Source: PoE (IEEE 802.3af class 0)
Power Draw: 6.48 Watts (Max)
Relay Output:
Relays 1-4: Form C 24V AC/DC 500mA
Relays 5-10: Form A 24V AC/DC 500mA
LAN: Ethernet (10BASE-T, 100BASE-TX)
Protocols: IPv4, IPv6, TCP, UDP, HTTP, HTTPS, SMTP, SFTP, DHCP, NTP, DNS
Encryption system: TLS1.2
Port Security: IEEE 802.1X
Operating Temp: 14° ~ 122°F (-10° ~ 50°C)
Dimensions: 7-½" H x 9-⅝" W x 13⁄16" D
